Parent SKU : TW6
SKU : TW6-250
APPLICATION:
Type W Cable is a heavy-duty, flexible portable power cable engineered for demanding industrial, commercial, and temporary power applications. Built with robust construction and a high 2000-volt rating, it excels in challenging environments due to its excellent resistance to oil, sunlight, flame, weather, impact, and abrasion, operating effectively from -40°C to +90°C. While primarily a portable solution, single-conductor Type W can also be dual-rated as RHH/RHW-2 for more permanent wiring uses.
CONDUCTOR:
Extra flexible stranded bare copper wires.
INSULATION:
Ethylene-propylene rubber (EPR).
JACKET:
Black heavy duty CPE thermosetting compound, impact and abrasion resistant.
REINFORCEMENT:
Single faced rubber filled binder tape over insulation.
FEATURES:
Excellent rated flexibility at -40°C to 90°C, water resistant and flame retardant, ozone, sunlight, oil, grease, weather, chemical and heat resistant.
BENDING RADIUS:
3.24 in.
AMP RATING:
@ 90°C - 105 Amps
Ampacities based on 90°C Conductor and 30°C Ambient temperature per table 400.5(A)(2) of the National Electrical Code.
| Wire Size (AWG/MCM) | 6 AWG |
| Conductor Material | Copper |
| Conductor Type | Stranded |
| Strand Count | 264 |
| Outer Diameter (OD) (in/mm) | 0.54 in. / 13.6 mm |
| Jacket Type | Black heavy duty CPE thermosetting compound |
| Conductor Count | 1 |
| Shield | Unshielded |
| Insulation Type | (EPR) Ethylene-propylene rubber |
| Voltage Rating | 2000V |
| Ampacity Rating | 105 |
| Submersible | No |
| Flexibility Rating | Very Good |
| Sunlight Resistance Rating | Yes |
| Temperature Rating | 90ºC |
| Standards | UL E207132 - Oil Resistant, Oil Resistant Inners, Sunlight Resistant, 90°C Wet or Dry C(UL) E207132 - FT1, FT5 -40°C to +90°C MSHA P-7K-268101 (for sizes 8AWG to 500MCM black) MSHA P-7K-268101 (for sizes 4AWG to 500MCM black and color) |
| Miscellaneous Information | Ampacities based on 90°C Conductor and 30°C Ambient temperature per table 400.5(A)(2) of the National Electrical Code |
| Other Certifications | MSHA |
| RoHS Compliance | Yes |
| Primary Applications | Type W cable is a heavy-duty, flexible portable power cable engineered for demanding industrial, commercial, and temporary power applications, thanks to its robust construction and high 2000 voltage rating. |
| Common Uses |
|
| Weight per Foot | 0.198 lb |
