SERVICE ENTRANCE CABLE

SER (Service Entrance, Round) and SEU (Service Entrance, Unarmored) Cables are both types of electrical cables responsible for bringing power from the utility grid directly to a home or building. SER cables are distinctively round, typically containing up to four conductors, including a bare neutral, and are generally installed above ground. In contrast, SEU cables have a flat design, featuring two-phase conductors and a concentric neutral, making them a common choice for feeding electrical panels in multi-unit dwellings.

Filters

0 Products

FIlters

SERVICE ENTRANCE CABLE

Service Entrance (SE) cables are specialized power conductors designed to deliver electricity from the utility transformer or service drop to the building’s main disconnect or distribution panel. Available in both aluminum and copper, these cables are categorized into two primary types: Style R (SER) and Style U (SEU). SER cable features a reinforced design with a dedicated grounding conductor, making it ideal for use as a sub-panel feeder or in branch circuits. SEU cable is an unarmored configuration with a concentric neutral, typically used for service drops from the utility to the meter socket. Both styles are insulated with sunlight-resistant, flame-retardant XLPE or THHN/THWN-2 materials, allowing for reliable 600V performance in both wet and dry environments.

Key Features
  • Reinforced Construction (SER): Includes two, three, or four phase conductors and a dedicated bare ground wire for comprehensive circuit protection.
  • Concentric Neutral (SEU): Features a neutral conductor wrapped concentrically around the phase wires, optimized for service entrance applications.
  • High-Performance Insulation: Conductors are protected by moisture-resistant, high-heat XLPE or PVC/Nylon insulation rated for 90°C.
  • Durable Outer Jacket: Encased in a sunlight-resistant, flame-retardant gray PVC jacket designed for long-term exposure to the elements.
  • Material Versatility: Available in lightweight 8000 Series Aluminum for cost-efficiency or High-Conductivity Copper for compact installations.
  • NEC Compliance: Manufactured to meet UL Standard 854 and fully compliant with National Electrical Code (NEC) Article 338.
Common Applications
  • Main Service Entrances: The standard cable for connecting the utility meter to the main service disconnect in residential buildings.
  • Sub-Panel Feeders: SER is frequently used to route power from a main distribution panel to a sub-panel in a garage, basement, or addition.
  • Branch Circuit Distribution: Deployed for high-amperage appliances such as electric ranges, clothes dryers, and HVAC units.
  • Manufactured Housing: Used as a feeder for mobile and modular homes where a separate ground and neutral are required.
  • Commercial Power Routing: Suitable for secondary power distribution in office buildings, retail spaces, and small industrial complexes.
  • Interior & Exterior Wiring: Approved for use as exposed or concealed wiring in both dry and wet locations above ground.
  • Renewable Energy Systems: Utilized as a feeder cable for solar inverter outputs and battery storage distribution panels.
