Solid THHN/THWN-2 WireFrom $0.20/ft -
Solid THHN/THWN-2 WireFrom $0.20/ft - Solid THHN/THWN-2 WireFrom $0.20/ft
- Solid THHN/THWN-2 WireFrom $0.20/ft
Parent SKU : BCTSTR2/0-7
SKU : BCTSTR2/0-7-250
"Designed for maximum corrosion resistance in the harshest environments, this 2/0 Tinned Stranded Copper wire is engineered for long-term performance. Featuring a high-purity copper core coated in a protective layer of tin, it provides the perfect balance of conductivity and chemical durability, making it the premier choice for marine, industrial, and high-moisture grounding systems."
The 2/0 Tinned conductor is the heavy-duty standard for environments where standard bare copper would fail. The tin coating acts as a permanent barrier against oxidation, salt air, and corrosive soil, ensuring your grounding system maintains its integrity for decades.
Superior Corrosion Resistance: The tin layer prevents the "greening" (oxidation) common in salt-air and high-humidity environments.
Ease of Termination: Tinned copper is significantly easier to solder and provides a cleaner, more reliable connection in mechanical lugs by preventing galvanic corrosion.
Soft-Drawn (Annealed): Despite the protective coating, the wire remains flexible for routing through marine hulls or industrial conduit.
7-Strand Construction: A rugged, high-strength design that offers excellent mechanical durability for demanding commercial and utility applications.
ENGINEERING OVERVIEW
Conductor Size: 2/0Â
Construction: 7-Strand
Material: Tinned Copper (Uninsulated)
Temper: Soft-Drawn (Annealed)
Overall Diameter: 0.414 inches (10.51 mm)
Approx. Weight: 410 lbs per 1,000 ftÂ
DC Resistance at 20ºC: 0.07949 Ohms/1000 ft.
Rated Strength: 4,062 lbs.
Standards: ASTM B-33 (Standard Spec for Tinned Soft/Annealed Copper), ASTM B-8.
Marine Power & Grounding: Used as the primary grounding bus and battery feeder for large commercial vessels and luxury yachts.
Wastewater Treatment Plants: Ideal for grounding systems in facilities where high humidity and corrosive gasses are present.
Coastal Site Development: The preferred grounding electrode conductor for residential and commercial structures located near the ocean.
Industrial Battery Banks: Used to interconnect large lead-acid battery banks where acid fumes would corrode standard bare copper.
Oil & Gas Infrastructure: Providing safety grounding for equipment in offshore and inland refinery environments.
Â
Technical Note: All values are nominal and subject to industry tolerances and manufacturer corrections. Specifications are subject to change without notice. It is the buyer’s responsibility to verify that all materials meet the specific requirements of the project and comply with local electrical codes.
Â
Â
| Wire Size (AWG/MCM) | 2/0 |
| Conductor Material | Tinned Copper |
| Conductor Type | Stranded |
| Strand Count | 7 |
| Outer Diameter (OD) (in/mm) | 0.414 in. |
| Conductor Count | 1 |
| Shield | Unshielded |
| Ampacity Rating | 355 |
| Direct Burial Rating | Yes |
| Submersible | No |
| Sunlight Resistance Rating | Yes |
| Standards | ASTM B-1 Hard-drawn copper wire ASTM B-2 Medium-hard drawn copper wire ASTM B-3 Soft or annealed copper wire ASTM B-8 Concentric-lay stranded copper conductors: hard, medium-hard, or soft ASTM B-33 Tinned soft or annealed copper wire ASTM B-258 Federal Sepc QQ-W-367 |
| Miscellaneous Information | All values are nominal and subject to correction. *Ampacity based on 75ºC conductor temperature; 25ºC ambient temperature; 2ft./sec. wind in sun. |
| Primary Applications | Grounding Systems, Overhead Power Distribution, Ground Wire for Lightning Protection, Bonding Applications, Messenger and Support Wires |
| Common Uses |
|
| Weight per Foot | 0.4109 lb |
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Parent SKU : BCTSTR2/0-7
SKU : BCTSTR2/0-7-250
Parent SKU : BCTSTR2/0-7
SKU : BCTSTR2/0-7-250
"Designed for maximum corrosion resistance in the harshest environments, this 2/0 Tinned Stranded Copper wire is engineered for long-term performance. Featuring a high-purity copper core coated in a protective layer of tin, it provides the perfect balance of conductivity and chemical durability, making it the premier choice for marine, industrial, and high-moisture grounding systems."
The 2/0 Tinned conductor is the heavy-duty standard for environments where standard bare copper would fail. The tin coating acts as a permanent barrier against oxidation, salt air, and corrosive soil, ensuring your grounding system maintains its integrity for decades.
Superior Corrosion Resistance: The tin layer prevents the "greening" (oxidation) common in salt-air and high-humidity environments.
Ease of Termination: Tinned copper is significantly easier to solder and provides a cleaner, more reliable connection in mechanical lugs by preventing galvanic corrosion.
Soft-Drawn (Annealed): Despite the protective coating, the wire remains flexible for routing through marine hulls or industrial conduit.
7-Strand Construction: A rugged, high-strength design that offers excellent mechanical durability for demanding commercial and utility applications.
ENGINEERING OVERVIEW
Conductor Size: 2/0Â
Construction: 7-Strand
Material: Tinned Copper (Uninsulated)
Temper: Soft-Drawn (Annealed)
Overall Diameter: 0.414 inches (10.51 mm)
Approx. Weight: 410 lbs per 1,000 ftÂ
DC Resistance at 20ºC: 0.07949 Ohms/1000 ft.
Rated Strength: 4,062 lbs.
Standards: ASTM B-33 (Standard Spec for Tinned Soft/Annealed Copper), ASTM B-8.
Marine Power & Grounding: Used as the primary grounding bus and battery feeder for large commercial vessels and luxury yachts.
Wastewater Treatment Plants: Ideal for grounding systems in facilities where high humidity and corrosive gasses are present.
Coastal Site Development: The preferred grounding electrode conductor for residential and commercial structures located near the ocean.
Industrial Battery Banks: Used to interconnect large lead-acid battery banks where acid fumes would corrode standard bare copper.
Oil & Gas Infrastructure: Providing safety grounding for equipment in offshore and inland refinery environments.
Â
Technical Note: All values are nominal and subject to industry tolerances and manufacturer corrections. Specifications are subject to change without notice. It is the buyer’s responsibility to verify that all materials meet the specific requirements of the project and comply with local electrical codes.
Â
Â
| Wire Size (AWG/MCM) | 2/0 |
| Conductor Material | Tinned Copper |
| Conductor Type | Stranded |
| Strand Count | 7 |
| Outer Diameter (OD) (in/mm) | 0.414 in. |
| Conductor Count | 1 |
| Shield | Unshielded |
| Ampacity Rating | 355 |
| Direct Burial Rating | Yes |
| Submersible | No |
| Sunlight Resistance Rating | Yes |
| Standards | ASTM B-1 Hard-drawn copper wire ASTM B-2 Medium-hard drawn copper wire ASTM B-3 Soft or annealed copper wire ASTM B-8 Concentric-lay stranded copper conductors: hard, medium-hard, or soft ASTM B-33 Tinned soft or annealed copper wire ASTM B-258 Federal Sepc QQ-W-367 |
| Miscellaneous Information | All values are nominal and subject to correction. *Ampacity based on 75ºC conductor temperature; 25ºC ambient temperature; 2ft./sec. wind in sun. |
| Primary Applications | Grounding Systems, Overhead Power Distribution, Ground Wire for Lightning Protection, Bonding Applications, Messenger and Support Wires |
| Common Uses |
|
| Weight per Foot | 0.4109 lb |
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Get notified when this product is back in stock
Physical Specifications
Technical Specifications
Usage & Installation:
Packaging & Dimensions:
|
||||||||||||||||||||||||||||||||
2/0 Tinned Copper is the industry standard for high-corrosion environments. It is most frequently used in marine grounding systems, coastal electrical services, and industrial facilities like chemical plants or water treatment centers where salt air or corrosive fumes would degrade standard bare copper.
The primary benefit is longevity. Standard bare copper will oxidize and turn green or black when exposed to moisture or salt. Tinned copper features a protective layer that stops this oxidation process, ensuring the wire maintains its low resistance and high conductivity for the life of the installation.
No. It is still a soft-drawn (annealed) conductor, so it remains flexible. In fact, many electricians prefer tinned copper because it is easier to solder and creates a more stable connection with mechanical lugs in wet environments.
Yes. Tinned copper is excellent for direct burial, especially in acidic or salty soils that are aggressive toward standard copper. It is often used in grounding rings for coastal substations.
The OD of our 2/0 Tinned Bare Copper Wire is approximately 0.414 inches.
