Parent SKU : MCCUSTR12-2
SKU : MCCUSTR12-2-250
12/2 Stranded Copper MC Cable W/ Ground is a heavy-duty 600V Metal-Clad (MC) building wire engineered for fast, reliable branch circuit wiring in commercial, industrial, institutional, and multi-residential structures. Constructed with two flexible 12 AWG stranded soft-drawn bare copper conductors, an insulated 12 AWG green ground wire, THHN/THWN-2 insulation, protective binder tape, and an overall aluminum interlocked armor, it delivers exceptional crush resistance and physical protection while drastically reducing labor costs compared to traditional pipe-and-wire installations.
Labor-Saving Metal-Clad Design: Pre-armored assembly eliminates the time-consuming process of pulling individual conductors through conduit, lowering jobsite labor costs and accelerating project timelines.
High-Flex Stranded Copper: Built with Class B stranded bare copper conductors to provide superior flexibility, easier pulls, and smooth terminations inside junction boxes and panel boards.
Dual-Rated THHN/THWN-2 Insulation: High-dielectric PVC insulation with a clear nylon outer skin provides superior heat, flame, moisture, and gasoline/oil resistance rated for 90°C dry applications.
Lightweight Aluminum Interlocked Armor: Tough interlocked aluminum armor (AIA) shields internal conductors from physical damage, crushing, and abrasion while maintaining maximum bendability.
Integrated Green Ground Conductor: Includes a dedicated 12 AWG green THHN/THWN-2 insulated stranded copper ground conductor for complete circuit safety.
Engineering Overview
Application: Branch, feeder, and distribution circuits in commercial, industrial, institutional, and multi-residential power, lighting, control, and signal systems.
Voltage Rating: 600 Volts.
Ampacity: 30 Amps @ 90°C (Based on 30°C ambient temperature per NEC Table 310.16; refer to NEC 240.4(D) for overcurrent protection limits).
Conductor Material: Class B stranded soft-drawn bare copper (2 conductors, 12 AWG).
Insulation: PVC (0.015" thickness) with clear Nylon jacket (0.004" thickness) (THHN/THWN-2).
Grounding Conductor: One 12 AWG green THHN/THWN-2 insulated stranded copper conductor.
Phase Identification: White, Black phase conductors (120V/208V system color code).
Armor: Overall lightweight aluminum interlocked armor.
Diameter over Armor: 0.51 inches (12.95 mm).
Approximate Net Weight: 122 lbs / 1,000 ft.
Temperature Rating: -40°C to +90°C Dry
Approvals & Compliance: UL Listed (UL 83, UL 1569, UL 1581), IEEE 1202 Vertical Tray Flame Test (70,000 BTU/hr), ASTM B3 & B8, Federal Spec A-A-59544, NEC Articles 230.43, 300.22, 330, 518.4, 520.5, 530, 545.4, 645. Hazardous Locations: Class I Div. 2, Class II Div. 2, Class III Div. 1 & 2.
** All values are nominal and subject to correction
| Wire Size (AWG/MCM) | 12 AWG |
| Conductor Material | Copper |
| Conductor Type | Stranded |
| Outer Diameter (OD) (in/mm) | 0.511 In. |
| Conductor Count | 2 |
| Shield | Unshielded |
| Insulation Type | PVC |
| UL Listing Numbers | UL 83, Ul 1569, UL 1581, UL 2556 |
| Voltage Rating | 600V |
| Ampacity Rating | 30 |
| Submersible | No |
| Temperature Rating | 90ºC |
| Standards | UL Standards 83, 1569, 1581 & 2556 IEEE 1202 vertical tray flame test, 70, 000 BTU/hr ASTM B3, B258 NEC Articles 300.22, 330, 518.4, 520.5, 530, 545.4 & 645 Class I Div. 2, Class II Div. 2 and Class III Div. 1 Div. 2 for hazardous locations Federal Specification A-A59544 |
| Miscellaneous Information | All values are nominal and subject to correction. |
| RoHS Compliance | Yes |
| Primary Applications | Commercial Branch Circuits, Industrial Facilities, Lighting Systems, Residential Multi-Family Housing, Environmental Air Spaces, Exposed and Concealed Wiring |
| Common Uses |
|
| Weight per Foot | 0.122 lb |
Real-world application examples are provided for educational and general planning purposes only. Project requirements vary based on system design, environmental factors, and local codes. Buyers and specifiers are responsible for verifying that all materials meet exact job specifications and comply with NEC and local electrical regulations. Always consult with a licensed electrician prior to installation.
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Parent SKU : MCCUSTR12-2
SKU : MCCUSTR12-2-250
Parent SKU : MCCUSTR12-2
SKU : MCCUSTR12-2-250
12/2 Stranded Copper MC Cable W/ Ground is a heavy-duty 600V Metal-Clad (MC) building wire engineered for fast, reliable branch circuit wiring in commercial, industrial, institutional, and multi-residential structures. Constructed with two flexible 12 AWG stranded soft-drawn bare copper conductors, an insulated 12 AWG green ground wire, THHN/THWN-2 insulation, protective binder tape, and an overall aluminum interlocked armor, it delivers exceptional crush resistance and physical protection while drastically reducing labor costs compared to traditional pipe-and-wire installations.
Labor-Saving Metal-Clad Design: Pre-armored assembly eliminates the time-consuming process of pulling individual conductors through conduit, lowering jobsite labor costs and accelerating project timelines.
High-Flex Stranded Copper: Built with Class B stranded bare copper conductors to provide superior flexibility, easier pulls, and smooth terminations inside junction boxes and panel boards.
Dual-Rated THHN/THWN-2 Insulation: High-dielectric PVC insulation with a clear nylon outer skin provides superior heat, flame, moisture, and gasoline/oil resistance rated for 90°C dry applications.
Lightweight Aluminum Interlocked Armor: Tough interlocked aluminum armor (AIA) shields internal conductors from physical damage, crushing, and abrasion while maintaining maximum bendability.
Integrated Green Ground Conductor: Includes a dedicated 12 AWG green THHN/THWN-2 insulated stranded copper ground conductor for complete circuit safety.
Engineering Overview
Application: Branch, feeder, and distribution circuits in commercial, industrial, institutional, and multi-residential power, lighting, control, and signal systems.
Voltage Rating: 600 Volts.
Ampacity: 30 Amps @ 90°C (Based on 30°C ambient temperature per NEC Table 310.16; refer to NEC 240.4(D) for overcurrent protection limits).
Conductor Material: Class B stranded soft-drawn bare copper (2 conductors, 12 AWG).
Insulation: PVC (0.015" thickness) with clear Nylon jacket (0.004" thickness) (THHN/THWN-2).
Grounding Conductor: One 12 AWG green THHN/THWN-2 insulated stranded copper conductor.
Phase Identification: White, Black phase conductors (120V/208V system color code).
Armor: Overall lightweight aluminum interlocked armor.
Diameter over Armor: 0.51 inches (12.95 mm).
Approximate Net Weight: 122 lbs / 1,000 ft.
Temperature Rating: -40°C to +90°C Dry
Approvals & Compliance: UL Listed (UL 83, UL 1569, UL 1581), IEEE 1202 Vertical Tray Flame Test (70,000 BTU/hr), ASTM B3 & B8, Federal Spec A-A-59544, NEC Articles 230.43, 300.22, 330, 518.4, 520.5, 530, 545.4, 645. Hazardous Locations: Class I Div. 2, Class II Div. 2, Class III Div. 1 & 2.
** All values are nominal and subject to correction
| Wire Size (AWG/MCM) | 12 AWG |
| Conductor Material | Copper |
| Conductor Type | Stranded |
| Outer Diameter (OD) (in/mm) | 0.511 In. |
| Conductor Count | 2 |
| Shield | Unshielded |
| Insulation Type | PVC |
| UL Listing Numbers | UL 83, Ul 1569, UL 1581, UL 2556 |
| Voltage Rating | 600V |
| Ampacity Rating | 30 |
| Submersible | No |
| Temperature Rating | 90ºC |
| Standards | UL Standards 83, 1569, 1581 & 2556 IEEE 1202 vertical tray flame test, 70, 000 BTU/hr ASTM B3, B258 NEC Articles 300.22, 330, 518.4, 520.5, 530, 545.4 & 645 Class I Div. 2, Class II Div. 2 and Class III Div. 1 Div. 2 for hazardous locations Federal Specification A-A59544 |
| Miscellaneous Information | All values are nominal and subject to correction. |
| RoHS Compliance | Yes |
| Primary Applications | Commercial Branch Circuits, Industrial Facilities, Lighting Systems, Residential Multi-Family Housing, Environmental Air Spaces, Exposed and Concealed Wiring |
| Common Uses |
|
| Weight per Foot | 0.122 lb |
Real-world application examples are provided for educational and general planning purposes only. Project requirements vary based on system design, environmental factors, and local codes. Buyers and specifiers are responsible for verifying that all materials meet exact job specifications and comply with NEC and local electrical regulations. Always consult with a licensed electrician prior to installation.
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Get notified when this product is back in stock
Physical Specifications
Technical Specifications
Usage & Installation:
Packaging & Dimensions:
|
||||||||||||||||||||||||||||||||||||
12/2 Stranded Copper MC Cable is a 600V metal-clad cable used for 120V/208V branch circuit power, lighting, and receptacle wiring in commercial, industrial, and multi-residential buildings. It features two 12 AWG stranded copper circuit conductors (Black/White) and one 12 AWG green insulated ground enclosed in an aluminum interlocked armor.
Solid MC cable uses single, solid copper wires, which are slightly stiffer to bend. Stranded MC cable utilizes Class B stranded copper wires, making the cable much more flexible, easier to pull through tight wall studs, and easier to bend into junction boxes without work-hardening the copper.
Yes. Because the aluminum interlocked armor provides continuous mechanical protection, MC cable is approved under NEC Article 330 to be installed directly inside walls, exposed across ceilings, or laid in cable trays without pulling through pipe or conduit.
Standard 12/2 MC cable with aluminum interlocked armor is designed for dry indoor applications (rated $90^\circ\text{C}$ Dry). For direct burial or wet outdoor environments, an PVC-jacketed MC cable (PVC over armor) or liquid-tight raceway system is required.
Under NEC Section 240.4(D), 12 AWG copper conductors are generally restricted to a maximum overcurrent protection rating of 20 Amps for standard branch circuits, despite having a higher raw conductor thermal ampacity rating (30A at 90°C).
Aluminum armor is significantly lighter in weight than steel armor—reducing freight costs, easing structural load on cable trays, and making jobsite pulls much faster for field installation crews—while maintaining full impact and crush protection.
