1/0 3C Type G-GC Mining Cable 2kV

1/0 3C Type G-GC 2000V Mining Cable W/ Dual Grounds & Ground Check is engineered for rugged underground and open-pit mining environments. It delivers continuous trailing power to heavy mobile equipment without tearing, cracking, or failing under extreme drag forces.

Constructed with three flexible 1/0 AWG tinned copper conductors (266 stranding), dual #5 AWG grounds, a dedicated #8 AWG ground-check wire, and a nylon-reinforced CPE jacket, it absorbs severe impact, oil, and rock abrasion across operating temperatures from -40°C to +90°C.

Key Features & Benefits

• Fail-Safe Ground Check Conductor: Features a dedicated yellow PP-insulated #8 AWG ground check wire that integrates with monitoring relays to instantly trip circuit breakers if ground continuity breaks.

• High-Flex Tinned Copper Stranding: Built with 266 strands of soft-drawn tinned copper for exceptional flexibility, extended flex life, and superior protection against wire fatigue under continuous dragging.

• Extreme Mechanical Durability: Reinforced with an internal open nylon braid and extra heavy-duty CPE compound to deliver outstanding impact, crush, tear, and severe rock abrasion resistance.

• All-Weather & Chemical Resistance: Highly resistant to oil, grease, water, ozone, chemicals, and direct sunlight/UV exposure, ensuring reliable performance in harsh outdoor and underground environments.

• High-Dielectric EPR Insulation: Ethylene-Propylene Rubber (EPR) insulation maintains superior thermal stability, dielectric strength, and flame resistance under continuous 2000V operating loads.

Technical Specifications

Engineering Overview

• Application: AC trailing power supply for off-track mining equipment, continuous miners, shuttle cars, drills, cutting machines, conveyors, and pumps.

• Voltage Rating: 2000 Volts (2kV).

• Ampacity: 205 Amps @ 90°C (Based on 30°C ambient temperature per NEC Table 400.5(A)(2)).

• Power Conductor Material: Annealed flexible stranded tinned copper (1/0 AWG, 266 stranding).

• Insulation: Ethylene-Propylene Rubber (EPR) (0.080" / 2.03 mm thickness).

• Grounding Conductors: Two annealed flexible stranded tinned copper grounds (2 #5 AWG) with green EPR insulation.

• Ground Check Conductor: One yellow polypropylene (PP) insulated flexible stranded tinned copper conductor (1 #8 AWG).

• Color Code: Black, White, Red phase identification.

• Jacket & Reinforcement: Black extra heavy-duty CPE thermosetting compound over an open nylon reinforcement braid.

• Cable Outer Diameter: 1.600 inches (40.64 mm).

• Approximate Weight: 2,206 lbs / 1,000 ft (3,283 kg/km).

• Minimum Bend Radius: 6 x cable outer diameter (9.60 inches).

• Temperature Rating: -40°C to +90°C (Wet or Dry).

• Approvals & Compliance: MSHA Approved (P-7K-268101), UL Listed Type G-GC 2000V 90°C Sun Res Oil Res, C(UL) FT1/FT5 (-40°C), ICEA S-75-381, CSA C22.2 No.96-13, ASTM B-33, UL 44, UL 1650.

Technical Note: All values are nominal and subject to industry tolerances and manufacturer corrections. Specifications are subject to change without notice. It is the buyer’s responsibility to verify that all materials meet the specific requirements of the project and comply with local electrical codes.

• Continuous Miners & Mobile Shuttle Cars: Delivers reliable 2000V trailing power across active mining faces, absorbing continuous twisting, sharp rock edge impacts, and dragging forces without shearing.
• Mine Dewatering & Sump Pumping: Extra heavy-duty CPE jacket and tinned copper conductors resist moisture, oil, and chemical exposure, providing continuous power to high-output dewatering pumps in harsh sumps and pits.
• Portable Core Drills & Rock Cutters: High-strand 266-wire tinned copper construction easily handles the vibration and mechanical flexing involved in mobile drilling operations.
• Aggregate Conveyors & Screening Equipment: Powers mobile material handling conveyors and crushers operating in high-dust, outdoor environments with constant sun and weather exposure.
• Temporary Jobsite Power Skids: Ideal flexible feed cable for temporary high-voltage power skids and generator sets requiring a fail-safe ground check circuit.

Real-world application examples are provided for educational and general planning purposes only. Project requirements vary based on system design, environmental factors, and local codes. Buyers and specifiers are responsible for verifying that all materials meet exact job specifications and comply with MSHA, NEC, and local electrical regulations. Always consult with a licensed electrical engineer prior to installation.
