Parent SKU : BDN5000FE
SKU : BDN5000FE-500
| Wire Size (AWG/MCM) | 12 AWG |
| Conductor Material | Bare Copper |
| Conductor Type | Stranded |
| Strand Count | 19 |
| Outer Diameter (OD) (in/mm) | 0.264 in. |
| Jacket Type | PVC |
| Conductor Count | 2 |
| Shield Coverage % | 1 |
| Shield Type | Bi-Laminate (Alum+Poly) |
| Shield | Shielded |
| Riser Rating | true |
| Insulation Type | PP - Polypropylene |
| UL Listing Numbers | UL1666 |
| Voltage Rating | 300V |
| Ampacity Rating | 30 |
| Submersible | No |
| Flexibility Rating | Very Good |
| Temperature Rating | -20°C To +75°C |
| Standards | Indoor - Riser, Indoor UL 1666 Riser, FT4, IEC 60332-1-2 CPR Euroclass: Eca Article 800, CMR CMG EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) UKCA Mark China RoHS II (GB/T 26572-2011) |
| Miscellaneous Information | Because pricing for the Belden 5100FE fluctuates based on copper market spot prices and volume requirements, we provide custom quotes to ensure you get the most competitive project rate. |
| RoHS Compliance | Yes |
| Primary Applications | Commercial Security Systems, Intercom & PA Systems, Access Control, Background Music (BGM), High-Rise Security Grids, Card Access Headers, Industrial Monitoring. |
| Common Uses |
|
| Weight per Foot | 0.059 lb |
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Get notified when this product is back in stock
Physical Specifications
Technical Specifications
Usage & Installation:
Packaging & Dimensions:
|
||||||||||||||||||||||||||||||||||||||||||||||||
The Belden 5000FE is a high-performance cable specifically designed for commercial sound, security, and control systems. Its 12 AWG thickness makes it ideal for long-distance speaker runs where voltage drop is a concern, as well as for intercom/PA systems and security control circuits that require a robust conductor and interference protection.
No. The 5000FE is CMR (Riser) rated, which means it is designed for vertical installations between floors (risers) and general-purpose in-wall use. It is not rated for use in environmental air plenums. If your project requires a plenum-rated cable, you should look for the Belden 6000FE equivalent.
This cable features Belden’s patented Beldfoil® shield (aluminum foil-polyester tape). The shield provides 100% coverage to protect your signal from electromagnetic interference (EMI) and radio frequency interference (RFI). It also includes a tinned copper drain wire for easy grounding of the shield, which is essential for maintaining clear audio and data signals in electronically "noisy" environments.
The 12 AWG (American Wire Gauge) conductor is significantly thicker than the standard 18 or 22 AWG used in basic security. This larger cross-sectional area provides lower resistance, which reduces signal loss over long distances. This makes it a preferred choice for high-power paging systems or long-run fire alarm and security sensors where maintaining signal integrity is critical.
The cable consists of two stranded bare copper conductors insulated with polypropylene. These are wrapped in the Beldfoil shield and encased in a PVC (Polyvinyl Chloride) jacket. It has a nominal outside diameter of approximately 0.260 inches, making it durable yet flexible enough for standard conduit pulls and wall installations.
