600 MCM 4C Twisted XHHW-2 Aluminum Feeder Cable, Priority-Plex®, (Brown, Orange, Yellow, Gray)

This 600 MCM 4-conductor Priority-Plex® assembly is a maximum-capacity power distribution solution specifically color-coded for 277/480V 3-phase, 4-wire systems. By factory-twisting the heavy-gauge Brown, Orange, Yellow, and Gray conductors into a single synchronized bundle, this cable eliminates the extreme difficulty of pulling four separate 600 MCM wires, significantly reducing labor and site logistics.

Why Choose Priority-Plex® 600 MCM Aluminum Feeder?

Handling 600 MCM conductors is one of the most physically demanding tasks in electrical construction. Priority-Plex® technology transforms this process by providing a pre-twisted circuit that behaves as a single unit, preventing the conductors from "wedging" or "crossing" during high-tension pulls in large conduits.

• Maximum Pull Efficiency: The twisted configuration reduces the surface contact area with the conduit wall, lowering friction and allowing for longer pulls with fewer pull-points.

• 480V System Identification: The factory-colored conductors (Brown, Orange, Yellow, Gray) provide permanent, high-visibility phase identification. This eliminates the need for field-taping and helps prevent catastrophic 480V/208V cross-wiring errors.

• Industrial-Grade Insulation: XHHW-2 (Cross-linked Polyethylene) offers superior thermal stability and moisture resistance, making it ideal for the high-heat environments common in high-amperage industrial services.

• Significant Cost Savings: At the 600 MCM scale, the price difference between aluminum and copper is substantial. AA-8000 series aluminum provides a lightweight, high-performance solution that drastically reduces total project material costs.

Technical Specifications: 600 MCM 4C

• Conductor Size: 600 MCM (kcmil)

• Number of Conductors: 4 (Brown, Orange, Yellow, Gray)

• Conductor Material: AA-8000 Series Aluminum Alloy

• Insulation Type: XHHW-2 (Cross-linked Polyethylene)

• Voltage Rating: 600V

• Temperature Rating: 90°C (Wet/Dry)

• Ampacity: 385 Amps (@ 90°C) | 340 Amps (@ 75°C)

• Configuration: Parallel-Twisted (Priority-Plex®)

Common Applications

• Industrial Main Services: The primary feeder for large-scale manufacturing facilities, powering massive motor control centers (MCCs).

• High-Rise Utility Risers: Ideal for vertical distribution in commercial towers to supply 277V lighting and 480V mechanical power to upper floors.

• Data Centers: Used for high-amperage 480V power distribution from main switchgear to secondary transformers or PDUs.

• Hospital Infrastructure: Providing reliable, high-capacity power for mission-critical mechanical systems and emergency backup distribution.

Technical Note: Due to the large diameter and weight of 600 MCM twisted bundles, ensure that your pulling equipment and tuggers are rated for the anticipated tension. Terminations must be made with AL9CU-rated connectors and an approved antioxidant compound. Always verify that the neutral (Gray) is correctly sized for any nonlinear or unbalanced loads.

CABLE CONFIGURATION: 4C (BRN-ORG-YEL-GRY) Twisted Bundle

PRIORITY PART#: 600-04PPLEX-BOYG
