6-6 Duplex Aluminum Overhead Service Drop Cable, Shepherd

Parent SKU :  SHP-2SDP

SKU :  SHP-2SDP-250

600 VOLT SUNLIGHT RESISTANT XLPE JACKET WITH BARE NEUTRAL MESSENGER.
Download Spec Sheet
6-6 Duplex Aluminum Overhead Service Drop Cable, Shepherd
Wire Size 6 AWG
Conductor Material Aluminum
Conductor Type Stranded
Outer Diameter 0.48 in.
Conductor Count 1
Voltage Rating 600
Ampacity Rating 85
Download Spec Sheet

Product Details

Product Details
APPLICATION:
Duplex Service Drop Aluminum Conductor Cable is designed for use to supply 120 volt aerial service for temporary service at construction sites, outdoor or street lighting. For service at 600 volts or lower at a conductor temperature of 75ºC maximum for polyethylene insulation or 90ºC maximum for cross linked insulation.

CONDUCTOR:
Concentric strand or compressed 1350-H19 series aluminum conductor.

CONDUCTOR SIZE:
6 AWG

BARE NEUTRAL MESSENGER:
Concentric strand AAC, ACSR, or AAAC 6201 alloy neutral messenger.

MESSENGER SIZE:
6 AWG

MESSENGER STRANDING:
6/1

BARE NEUTRAL BREAKING STRENGTH:
1,190 lbs.

ASSEMBLY:
Two twisted conductors, an insulated aluminum phase conductor and a bare neutral messenger, which also serves as the self-supporting element.

INSULATION:
Black cross linked polyethylene (XLP) insulation.

AMP RATING:
90ºC - 85 Amps



All values are nominal and subject to correction *Designated sizes are ACSR 6/1, diameter, equivalent resistivity per ASTM B399 for 6201. **Conductor temperature of 90ºC for XLP, 75ºC for Poly; ambient temperature of 40ºC, emissivity 0.9; 2ft/sec. wind in sun.

Full Specifications

Full Specifications
Download Spec Sheet

Physical Specifications

Wire Size (AWG/MCM) 6 AWG
Conductor Material Aluminum
Conductor Type Stranded
Strand Count 7
Outer Diameter (OD) (in/mm) 0.48 in.
Conductor Count 1
Shield Unshielded
Insulation Type (XLPE) Cross-Linked Polyethylene

Technical Specifications

Voltage Rating 600
Ampacity Rating 85
Submersible No
Sunlight Resistance Rating Yes
Temperature Rating 90ºC
Standards ASTM B-230 Aluminum 1350–H19 Wire for Electrical Purposes
ASTM B-231 Concentric-Lay-Stranded Aluminum 1350 Conductors
ASTM B-232 Concentric-Lay-Stranded Aluminum Conductors, Coated-Steel Reinforced (ACSR)
ASTM B-399 Concentric-Lay-Stranded Aluminum-Alloy 6201-T81 Conductors
ICEA S-76-474 Neutral-Supported Power Cable Assemblies with Weather-Resistant Extruded Insulation Rated 600 Volts
RUS Accepted
Miscellaneous Information All values are nominal and subject to correction *Designated sizes are ACSR 6/1, diameter, equivalent resistivity per ASTM B399 for 6201. **Conductor temperature of 90ºC for XLP, 75ºC for Poly; ambient temperature of 40ºC, emissivity 0.9; 2ft/sec. wind in sun.

Usage & Installation

Primary ApplicationsOverhead Electrical Service
Common Uses
  • Residential Power Supply
  • Commercial and Industrial Power Supply
  • Temporary Service for Construction Sites
  • Outdoor Lighting
  • Secondary Distribution Between Poles.

Packaging & Dimensions:

Weight per Foot 0.078 lb
