10/3 SJOOW Flexible Cord | 300V

Parent SKU :  SJOOW10-3

SKU :  SJOOW10-3-250

RUBBER DURABLE JACKET. SUNLIGHT, OIL & WATER RESISTANT. UL/CSA
Download Spec Sheet
10 AWG 3C SJOOW portable cord, 300V flexible power cable with oil, water, and sunlight resistant jacket for indoor/outdoor.
Wire Size 10 AWG
Conductor Material Copper
Outer Diameter 0.58 in. / 14.732 mm
Jacket Type EPDM Rubber
Conductor Count 3
Voltage Rating 300V
Ampacity Rating 30
Download Spec Sheet

Product Details

Product Details
SJOOW portable power cord is a widely used, flexible, and heavy-duty electrical cable suitable for both indoor and outdoor applications. Its designation breaks down its key features: the "S" means Service (indicating a robust cable), the "J" denotes Junior Service (meaning it's rated for 300 volts, unlike 600-volt "S" cords), "OO" signifies both oil-resistant insulation and an oil-resistant outer jacket, and "W" indicates weather and water resistance. This combination makes SJOOW cable exceptionally durable against abrasion, heat, and moisture, while remaining flexible enough to power portable tools, small motors, temporary lighting, and extension cords effectively.

JACKET:
Overall jacket of black Chlorinated Polyethylene (CPE).

CONDUCTOR COLORS:
Black, White and Green

AMP RATING:
30 Amps

ICEA S-58-679, Method 1, Table 1

Full Specifications

Full Specifications
Download Spec Sheet

Physical Specifications

Wire Size (AWG/MCM) 10 AWG
Conductor Material Copper
Conductor Type Stranded
Strand Count 103/30
Outer Diameter (OD) (in/mm) 0.58 in. / 14.732 mm
Jacket Type EPDM Rubber
Conductor Count 3
Shield Unshielded
Insulation Type Ethylene Propylene Diene Monomoer (EPDM) or Ethylene Propylene Rubber (EPR)
UL Listing Numbers UL/CSA

Technical Specifications

Voltage Rating 300V
Ampacity Rating 30
Submersible No
Flexibility Rating High
Sunlight Resistance Rating Yes
Temperature Rating 90ºC
Standards UL Flexible Cord - UL 62
CSA C22.2 No. 49
Flame test meets FT2
ASTM B-174
MSHA Approved
OSHA Accepted
RoHS Compliant
Miscellaneous Information All values are nominal and subject to correction. **Ampacity values shown are for current carrying conductors. A grounding conductor, or one which carries only the unbalanced current from other conductors, is NOT counted in determining current carrying capacity.
RoHS Compliance Yes

Usage & Installation

Primary ApplicationsPortable tools and equipment, portable appliances, small motors, machinery.
Common Uses
  • Temporary Power Supplies
  • Portable Tools and Equipment
  • Lighting Installations
  • Sound and Audio Equipment
  • Industrial Machinery
  • Marine Applications
  • Heating and Cooling Equipment.

Packaging & Dimensions:

Weight per Foot 0.225 lb
