Parent SKU : FAP-SHDNY16-1P
SKU : FAP-SHDNY16-1P-250
APPLICATION:
Our 16/2 Shielded NYC Certified Plenum Rated Fire Alarm Cable is used for wiring fire alarms, smoke detectors, voice communications, burglar alarms, and approved for NYC LL39 (formerly LL5) fire protective circuits installed in the City of New York. Applications not to exceed 300 volts, suitable for use up to 200°C.
CONDUCTORS:
Fully annealed solid bare copper per ASTM B3 & B258.
DRAIN WIRE:
Solid 24AWG tinned copper drain wire.
ASSEMBLY:
Insulated conductors cabled together with or without shield under an overall jacket. Ripcord and sequential footage markings to facilitate installation.
CONDUCTOR COLORS:
Black and Red
JACKET COLOR:
Red
INSULATION:
Premium-grade, color-coded FEP.
Why Professionals Choose This NYC Certified Cable:
Local Law 39 (LL39) Compliant: Fully classified by UL/ETL for NYC certified fire alarm installations.
High-Heat Resilience: Rated for 200°C, providing superior survivability compared to standard 75°C or 105°C fire wire.
Superior FEP Insulation: Features Fluorinated Ethylene Propylene (FEP) insulation and jacketing, which is chemically resistant, easy to strip, and ultra-durable.
100% Shielding: Equipped with an aluminum/polyester foil shield and a tinned copper drain wire to eliminate interference in noisy environments like elevator shafts.
NYC Code Installer Tip:
New York City requires fire alarm cables in plenum spaces to be FPLP and often specifies a 200°C rating for specific high-rise and voice-communication circuits. Always ensure your cable is printed with "NYC CERT. FIRE ALARM" and "LL39" to pass inspection.
All values are nominal and subject to correction.
| Wire Size (AWG/MCM) | 16 |
| Conductor Material | Copper |
| Conductor Type | Solid |
| Strand Count | 1 |
| Outer Diameter (OD) (in/mm) | 0.217 in. / 5.51 mm |
| Jacket Type | Plenum-Rated FEP |
| Conductor Count | 2 |
| Shield Coverage % | 1 |
| Shield Type | Overall polyester-backed aluminum foil with a solid 24 AWG tinned copper drain wire. |
| Shield | Shielded |
| Insulation Type | (FEP) Fluorinated Ethylene Propylene |
| UL Listing Numbers | UL 13, UL 444, UL1424 |
| Plenum Rating | true |
| Voltage Rating | 300V |
| Submersible | No |
| Flexibility Rating | Very Good |
| Temperature Rating | 200ºC |
| Standards | NYC Local Law 39 (Formerly LL5) UL 13 Power-Limited Circuit Cable UL 444 Communication Cables UL1424 Cables for Power-Limited Fire-Alarm Circuits UL Listed Type FPLP, 200°C NFPA 262 Test for Flame Travel and Smoke of Wires and Cables for Use in Air Handling Spaces NEC Article 725, 760, 808 |
| Miscellaneous Information | All values are nominal and subject to correction. |
| Other Certifications | NYC LL5/LL39 |
| RoHS Compliance | Yes |
| Primary Applications | NYC LL39 (formerly LL5) fire protective circuits installed in the City of New York. |
| Common Uses |
|
| Weight per Foot | 0.039 lb |
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Parent SKU : FAP-SHDNY16-1P
SKU : FAP-SHDNY16-1P-250
Parent SKU : FAP-SHDNY16-1P
SKU : FAP-SHDNY16-1P-250
APPLICATION:
Our 16/2 Shielded NYC Certified Plenum Rated Fire Alarm Cable is used for wiring fire alarms, smoke detectors, voice communications, burglar alarms, and approved for NYC LL39 (formerly LL5) fire protective circuits installed in the City of New York. Applications not to exceed 300 volts, suitable for use up to 200°C.
CONDUCTORS:
Fully annealed solid bare copper per ASTM B3 & B258.
DRAIN WIRE:
Solid 24AWG tinned copper drain wire.
ASSEMBLY:
Insulated conductors cabled together with or without shield under an overall jacket. Ripcord and sequential footage markings to facilitate installation.
CONDUCTOR COLORS:
Black and Red
JACKET COLOR:
Red
INSULATION:
Premium-grade, color-coded FEP.
Why Professionals Choose This NYC Certified Cable:
Local Law 39 (LL39) Compliant: Fully classified by UL/ETL for NYC certified fire alarm installations.
High-Heat Resilience: Rated for 200°C, providing superior survivability compared to standard 75°C or 105°C fire wire.
Superior FEP Insulation: Features Fluorinated Ethylene Propylene (FEP) insulation and jacketing, which is chemically resistant, easy to strip, and ultra-durable.
100% Shielding: Equipped with an aluminum/polyester foil shield and a tinned copper drain wire to eliminate interference in noisy environments like elevator shafts.
NYC Code Installer Tip:
New York City requires fire alarm cables in plenum spaces to be FPLP and often specifies a 200°C rating for specific high-rise and voice-communication circuits. Always ensure your cable is printed with "NYC CERT. FIRE ALARM" and "LL39" to pass inspection.
All values are nominal and subject to correction.
| Wire Size (AWG/MCM) | 16 |
| Conductor Material | Copper |
| Conductor Type | Solid |
| Strand Count | 1 |
| Outer Diameter (OD) (in/mm) | 0.217 in. / 5.51 mm |
| Jacket Type | Plenum-Rated FEP |
| Conductor Count | 2 |
| Shield Coverage % | 1 |
| Shield Type | Overall polyester-backed aluminum foil with a solid 24 AWG tinned copper drain wire. |
| Shield | Shielded |
| Insulation Type | (FEP) Fluorinated Ethylene Propylene |
| UL Listing Numbers | UL 13, UL 444, UL1424 |
| Plenum Rating | true |
| Voltage Rating | 300V |
| Submersible | No |
| Flexibility Rating | Very Good |
| Temperature Rating | 200ºC |
| Standards | NYC Local Law 39 (Formerly LL5) UL 13 Power-Limited Circuit Cable UL 444 Communication Cables UL1424 Cables for Power-Limited Fire-Alarm Circuits UL Listed Type FPLP, 200°C NFPA 262 Test for Flame Travel and Smoke of Wires and Cables for Use in Air Handling Spaces NEC Article 725, 760, 808 |
| Miscellaneous Information | All values are nominal and subject to correction. |
| Other Certifications | NYC LL5/LL39 |
| RoHS Compliance | Yes |
| Primary Applications | NYC LL39 (formerly LL5) fire protective circuits installed in the City of New York. |
| Common Uses |
|
| Weight per Foot | 0.039 lb |
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Get notified when this product is back in stock
Physical Specifications
Technical Specifications
Usage & Installation:
Packaging & Dimensions:
|
||||||||||||||||||||||||||||||||||||||||||||||||
New York City requires fire alarm cables to meet specific standards beyond standard NEC rules, specifically Local Law 39 (LL39) and Local Law 5. This means the cable must feature specialized insulation (like FEP or ECTFE) that is flame-retardant and low-smoke, often with a higher temperature rating (150°C to 200°C) than standard fire alarm wire.
Unshielded: Ideal for most standard notification appliance circuits (NACs) and pull stations where electromagnetic interference (EMI) is not a concern.
Shielded: Required for data communication links (SLC loops) or installations near high-voltage lines, elevator motors, or fluorescent lighting to prevent signal interference and false alarms.
16/2 NYC Fire Alarm Cable is most commonly used for Notification Appliance Circuits (NACs). While 18 AWG is often sufficient for sensors, 16 AWG is the preferred "step up" for powering horns, strobes, and bells in New York City commercial buildings and high-rises.
In the NYC market, 16/2 cable is specifically utilized for:
NYC Approved FPLP (Plenum): Must be used in "plenum" spaces—areas used for air circulation, like above drop ceilings or under raised floors. These have a low-smoke, high-fire-resistance jacket.
NYC Approved FPLR (Riser): Used for vertical runs between floors (risers). In NYC, most commercial specs call for FPLP even in non-plenum areas for maximum safety, but check your specific building code.
Choosing 16/2 NYC Fire Alarm Cable over 18/2 typically comes down to two factors: distance and current draw. * Longer Initiating Loops: While 18/2 is standard for smoke detectors, 16/2 is the preferred choice for longer runs where signal integrity is a concern. The thicker 16 AWG copper reduces resistance, ensuring the fire alarm control panel receives a clear signal from the furthest device.
