Parent SKU : BDN5303FE
SKU : BDN5303FE-500
| Wire Size (AWG/MCM) | 18 AWG |
| Conductor Material | Bare Copper |
| Conductor Type | Stranded |
| Strand Count | 7 |
| Outer Diameter (OD) (in/mm) | 0.197 in. |
| Jacket Type | PVC |
| Conductor Count | 5 |
| Shield Coverage % | 1 |
| Shield Type | Bi-Laminate (Alum+Poly) |
| Shield | Shielded |
| Riser Rating | true |
| Insulation Type | PO - Polyolefin |
| UL Listing Numbers | UL1666 |
| Voltage Rating | 300V |
| Ampacity Rating | 4 |
| Submersible | No |
| Flexibility Rating | Very Good |
| Temperature Rating | -20°C To +75°C |
| Standards | Indoor - Riser, Indoor UL 1666 Riser, FT4, IEC 60332-1-2 CPR Euroclass: Eca Article 800, CMR CMG EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) UKCA Mark China RoHS II (GB/T 26572-2011) |
| Miscellaneous Information | Because pricing for the Belden 5303FE fluctuates based on copper market spot prices and volume requirements, we provide custom quotes to ensure you get the most competitive project rate. |
| RoHS Compliance | Yes |
| Primary Applications | Commercial Security Systems, Intercom & PA Systems, Access Control, Background Music (BGM), High-Rise Security Grids, Card Access Headers, Industrial Monitoring. |
| Common Uses |
|
| Weight per Foot | 0.039 lb |
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Get notified when this product is back in stock
Physical Specifications
Technical Specifications
Usage & Installation:
Packaging & Dimensions:
|
||||||||||||||||||||||||||||||||||||||||||||||||
The Belden 5303FE is a multi-conductor shielded cable designed for professional sound, security, and building automation systems. With five 18 AWG conductors, it is commonly used for applications such as PTZ (Pan-Tilt-Zoom) camera controls, access control readers that require extra lines for LEDs or buzzers, and multi-zone audio systems. The 18-gauge size ensures that both power and signals can be delivered reliably over longer distances than standard 22 AWG wire.
No. The 5303FE is CMR (Riser) rated, which means it is designed for vertical installations in building shafts (risers) and general-purpose in-wall use. It is not rated for use in environmental air plenums. If your project requires the cable to be run in a plenum-rated ceiling or air-handling space, you must use the plenum-rated equivalent, Belden 6303FE.
This cable features Belden’s patented Beldfoil® shield (aluminum foil-polyester tape), providing 100% coverage. This shielding is essential for protecting sensitive electronic signals from electromagnetic interference (EMI) and radio frequency interference (RFI), which can cause signal distortion or system errors. It also includes a 24 AWG tinned copper drain wire to ensure a consistent and easy-to-terminate ground connection.
The 18 AWG (American Wire Gauge) stranded bare copper conductors offer lower electrical resistance, which is vital for preventing voltage drop in power-carrying lines. The 5-conductor configuration provides great versatility, allowing for complex wiring setups—such as power, ground, and three separate signal or data lines—to be pulled in a single jacket, saving time and labor during installation.
The 5303FE is constructed with five stranded bare copper conductors insulated with polypropylene (PP). The assembly is protected by the overall foil shield and encased in a durable PVC (Polyvinyl Chloride) jacket. It has a nominal outside diameter of approximately 0.205 inches. This thin, flexible profile makes it easy to pull through conduit and maneuver within tight wall cavities or electrical boxes.
