Parent SKU : BDN5301FE
SKU : BDN5301FE-500
| Wire Size (AWG/MCM) | 18 AWG |
| Conductor Material | Bare Copper |
| Conductor Type | Stranded |
| Strand Count | 7 |
| Outer Diameter (OD) (in/mm) | 0.165 in |
| Jacket Type | PVC |
| Conductor Count | 3 |
| Shield Coverage % | 1 |
| Shield Type | Bi-Laminate (Alum+Poly) |
| Shield | Shielded |
| Riser Rating | true |
| Insulation Type | PO - Polyolefin |
| UL Listing Numbers | UL1666 |
| Voltage Rating | 300V |
| Ampacity Rating | 5 |
| Submersible | No |
| Flexibility Rating | Very Good |
| Temperature Rating | -20°C To +75°C |
| Standards | Indoor - Riser, Indoor UL 1666 Riser, FT4, IEC 60332-1-2 CPR Euroclass: Eca Article 800, CMR CMG EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) UKCA Mark China RoHS II (GB/T 26572-2011) |
| Miscellaneous Information | Because pricing for the Belden 5301FE fluctuates based on copper market spot prices and volume requirements, we provide custom quotes to ensure you get the most competitive project rate. |
| RoHS Compliance | Yes |
| Primary Applications | Commercial Security Systems, Intercom & PA Systems, Access Control, Background Music (BGM), High-Rise Security Grids, Card Access Headers, Industrial Monitoring. |
| Common Uses |
|
| Weight per Foot | 0.026 lb |
In-stock orders placed before 3pm EST typically ship within 1-2 business days. Our business days are Monday through Friday; we do not process orders on Saturday, Sunday, or major US Holidays.
You will receive an e-mail with a tracking number within 1-2 business days from the time its shipped. You will also be able to view your order status and tracking numbers in your account order history.
Expedited shipments are delivered Monday-Friday except on US Holidays. The order must be placed before 12pm CST to ship same day ( Mon-Fri Only).
You have 30 days from the day you receive the item to contact us for a return. Returns are subject to a 30% Restocking Fee.
Please contact us at help@wireamerica.com to request a return authorization. Have your order number or name the order was placed with ready and we will email you an RMA (return) number and instructions for return. Currently, we do not offer exchanges. A new order must be placed if you need a different item. If you provide the new order number at the time of your return request, the restocking fee may be lowered.
Orders on any items with a material value of $50 or less are non-returnable.
Get notified when this product is back in stock
Physical Specifications
Technical Specifications
Usage & Installation:
Packaging & Dimensions:
|
||||||||||||||||||||||||||||||||||||||||||||||||
The Belden 5301FE is a versatile 3-conductor shielded cable engineered for commercial sound and security environments. It is frequently used for balanced audio line connections, intercom systems, and security sensors that require a third wire for power or ground. Its 18 AWG gauge is a standard choice for mid-range runs where maintaining signal integrity and providing adequate power to devices like card readers or motion detectors is essential.
No. The 5301FE carries a CMR (Riser) rating, meaning it is designed for vertical installations in building shafts and general-purpose in-wall use. It has been fire-tested to ensure it does not easily carry a flame between floors, but it does not meet the strict low-smoke and low-flame requirements for environmental air plenums. For installations requiring a plenum rating, you must use the Belden 6301FE.
This cable features Belden’s proprietary Beldfoil® shield, an aluminum foil-polyester tape that provides 100% coverage around the conductors. This shield is critical for blocking electromagnetic interference (EMI) and radio frequency interference (RFI) that can cause "hum" in audio or false triggers in security systems. It includes a 24 AWG tinned copper drain wire to ensure a quick and effective ground termination for the shield.
The 18 AWG (American Wire Gauge) stranded bare copper conductors have a larger cross-section, which results in significantly lower electrical resistance. This is vital for reducing voltage drop over long cable runs, ensuring that devices like electric door strikes or high-output speakers receive the power they need to operate reliably. The extra copper also makes the cable more physically robust during the pulling process.
The cable is constructed with three stranded bare copper conductors insulated with polypropylene (PP). The assembly is protected by the overall Beldfoil shield and encased in a durable PVC (Polyvinyl Chloride) jacket. It has a nominal outside diameter of approximately 0.172 inches. This slim profile, combined with the flexibility of stranded conductors, allows for easier navigation through conduit and tight wall cavities.
