Solid THHN/THWN-2 WireFrom $0.20/ft -
Solid THHN/THWN-2 WireFrom $0.20/ft - Solid THHN/THWN-2 WireFrom $0.20/ft
- Solid THHN/THWN-2 WireFrom $0.20/ft
Parent SKU : PLTC16-2P-SPOS
SKU : PLTC16-2P-SPOS-250
| Wire Size (AWG/MCM) | 16 AWG |
| Conductor Material | Copper |
| Conductor Type | Stranded |
| Strand Count | 7 |
| Outer Diameter (OD) (in/mm) | 0.298 in. / 7.57 mm |
| Jacket Type | (PVC) Polyvinyl Chloride |
| Conductor Count | 4 |
| Shield Coverage % | 100 |
| Shield Type | Aluminum Mylar Foil |
| Shield | Individual and Overall Shield |
| Insulation Type | (PVC) Polyvinyl Chloride |
| UL Listing Numbers | PLTC, UL 13, UL 2250, UL 1202 |
| Voltage Rating | 300V |
| Direct Burial Rating | Yes |
| Submersible | No |
| Sunlight Resistance Rating | Yes |
| Temperature Rating | 105ºC |
| Standards | UL listed as type PLTC & CL3 per UL standard 13 and as, type ITC per UL standard 2250 Suitable for installations under NEC (NFPA 70) article 725, and article 727 guidelines Suitable for use in Class I Division 2 hazardous locations EPA 40 CFR, part 261 Cold bend rating of -40°C, UL approved for Sunlight Resistant Applications meets IEEE, 1202 flame test (UL) ITC Sunlight Resistant or PLTC or CL3 FT4 REACH compliant per Regulation (EC) No 1907/2006 (219) |
| Miscellaneous Information | All values are nominal and subject to correction |
| RoHS Compliance | Yes |
| Primary Applications | Industrial Process Control Systems, Instrumentation and Data Acquisition, Hazardous (Class I & II, Division 2) Locations, Cable Tray Installations, Noise-Sensitive Environments, Security and Access Control Systems, Fire Alarm Systems. |
| Common Uses |
|
| Weight per Foot | 0.071 lb |
